Single Lane 100mm Facial Tissue Paper Cutting Machine

Single Lane 100mm Facial Tissue Paper Cutting Machine
Single Lane 100mm Facial Tissue Paper Cutting Machine

Large Image :  Single Lane 100mm Facial Tissue Paper Cutting Machine

Product Details:
Place of Origin: CHINA
Brand Name: ACE
Certification: CE
Model Number: FLS
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $15000 - 50000
Packaging Details: standard export packing
Delivery Time: 60 days
Payment Terms: L/C, T/T
Supply Ability: 20 set /month
Detailed Product Description
Product: High Speed Automatic Tissue Paper Cutting Machine For Facial Tissue Papers Application: Facial Tissue Papers
Cut Speed: 140 Cut/min Chanels: Single Lane
Control: PLC Touch Screeen: Siemens
High Light:

100mm Tissue Paper Cutting Machine

,

Single lane facial tissue paper making machine

,

100mm tissue paper cutter machine

High speed Automatic tissue paper cutting machine for facial tissue papers


Quick details:
1 For cutting facial tissue paper and hand towels
2 High speed 140 cut/min
3 Single lane
4 Servo motor control
5 Big ranges of cutting sizes

FLS Fully Automatic High Speed Tissue Cutter
Main structure: single channel.
Applicable material: facial tissues
Designed speed: 150 cut/min
Working speed: 80-140 cut/min
when cutting length 100mm, about 140 cut/min;
when cutting length 230mm, about 120 cut/min.
Infeed channel: With 1 piece of infeed conveyor 3 meters length.
Cutting delivery system: Independent servo control and driving.
Cutting sizes ranges: L 60-300mm adjustable
                                  W 60-110mm
                                  H 25-120mm
Cutting tolerance length: ±1mm
Cutting tolerance vertical: ±1.5mm
Output delivery: During the whole log saw cutting process, the tissues are pressed by Top timing belts + bottom timing belts to prevent the belts getting slippery and guarantee every cut accurate cutting. (But other company machines use flat belts which would definitely get slippery and no-accurate cutting.)
Adopt 2 servo motors to control the timing belts before the circular blade cutting and after the circular blade cutting .(But other companies’ machines use only one servo motor or NO servo motor, controlled by only inverter, which cannot guarantee accurate cutting.)
Circular blade outer diameter: 610mm
Blade grinding/sharpening system: Automatically and pneumatically grinding/sharpening, grinding/sharpening time and interval parameters can be set in the touch screen. For example, you can set it to sharpen for 1 seconds every 30 minutes or every 50 cuts.
Cutting system: 360° rotating cutting. (Not like other companies machines, the cutting system is only up-and-down cutting.)
Trim removal system: Automatically blew away by air. Trimmed size: 20-65mm.
Control system:
PLC programmed control,
Inverter for variable frequency speed control,
Touch screen for operation
Servo driving: adopt 2 servo motors to control the timing belts before the circular blade cutting and after the circular blade cutting .(But other companies’ machines use only one servo motor or NO servo motor, controlled by only inverter, which cannot guarantee accurate cutting.)
Air compressor: 4-8kg/cm2pa, supplied by customer.
Installed Power: 3phase 208v 60hz. total about 6.4kw
Servo system power: about 2 kw
Rotate motor power: about 2.2kw
Blade motor power: about 2.2kw
Machine weight: about 2T.
Machine dimension: about 5x1.9x1.95m LxWxH. Floor plan refer to below.



Technical parameters

Main structure: Single lane cutting
Applicable material Facial tissue and hand towel
Designed speed: 150 cut/min
Working speed:

80-140 cut/min

when cutting length 100mm, about 140 cut/min;

when cutting length 230mm, about 120 cut/min.

Infeed channel: With one piece infeed conveyor 3meters
Cutting delivery system Independent servo control and driving.
Cutting sizes ranges:

L 60-300mm adjustable

W 60-110mm

H 25-120mm

Cutting tolerance length: ±1mm
Cutting tolerance vertical: ±1.5mm




Finished products of this High speed Automatic tissue paper cutting machine for facial tissue papers.
Automatic tissue paper cutting machine
