2 Colors Printing N Fold Napkin Making Machine With 2 Channels 2500 Napkin/Minutes

2 Colors Printing N Fold Napkin Making Machine With 2 Channels 2500 Napkin/Minutes
2 Colors Printing N Fold Napkin Making Machine With 2 Channels 2500 Napkin/Minutes
video play

Large Image :  2 Colors Printing N Fold Napkin Making Machine With 2 Channels 2500 Napkin/Minutes

Product Details:
Place of Origin: China
Brand Name: ACE
Certification: CE
Model Number: ACE-TNM-2L
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: standard export packing
Delivery Time: 60 days
Payment Terms: L/C, T/T
Supply Ability: 10 set /month
Detailed Product Description
Name: N Fold Napkin Machine Embossing: Steel To Wool Or Paper
Design: Taiwan Technology Folding Type: 1/6 N Fold
Speed: Up To 2500 Napkin/minute Printing: 2 Colors Printing With Ceramic Anilox Roller
High Light:

N Fold Napkin Making Machine

,

2 Channels Napkin Making Machine

,

2500 Napkin/Minutes Napkin Paper Machine



High Speed Taiwan Technology Z2 Colors Printing N Fold Napkin Making Machine With 2 Channels 2500 Napkin/Minutes 330*165mm


Application of this Taiwan Technology 2 Colors Printing N Fold Napkin Making Machine With 2 Channels 2500 Napkin/Minutes.
This ACE-TNM-2L Taiwan Technology 2 Colors Printing N Fold Napkin Making Machine With 2 Channels 2500 Napkin/Minutes is mainly used to automatically fold, emboss, print, cut and count 1/4 fold table napkins, cocktail napkin, restaurant napkins, beverage napkin, lunchen napkin, 1/6 fold tallfold dispenser napkin, wallet tissue and MG paper napkins etc. The mainly function of this machine is to manufacture plain, embossed and LOGO printed tissue paper napkins. It can run at very high speed up to 2600 sheets per minute.

Quick details:
1 Tall fold napkin Size 330*165mm or customized.
2 Steel to paper embossing unit
3 two colors printing napkin machine
4 mechanical 1/4 1/6 Z fold, N fold, 1/8 fold
5 High speed 2600 sheet/min

Technical parameters
ACE-TNM-2L Taiwan Technology 2 Colors Printing N Fold Napkin Making Machine With 2 Channels 2500 Napkin/Minutes.

Model ACE-TNM-2L
Output type

2 decks
2 lanes
2 channels
4 lines

Folding speed 1000-2600 piece/min, depending on the paper quality and napkin size.
Raw paper

13-20g/m2 2-ply, 16-45g/m2 1-ply, wooden pulp paper or nonwoven airlaid.
Other sizes please specify.

Jumbo roll size (200-460)mm x Φ1200mm (Depending on your napkin size,customized)
Napkin unfolded size

200mm x 200mm to 460mm x 460mm or Customized.
For tall fold dispenser napkin open size 330*165mm.

Napkin folded size

100mm x 100mm to 230mm x 230mm.
For tall fold dispenser napkin folded size 330*85mm.
One size is fixed.
One napkin size is adjustable, decided by the paper roll width.

Folding type

Mechanical fold with band saw cutting;
1/4 fold;
1/6 fold napkin
Z fold napkin
N fold napkin
Vacuum folding and other folding types available

Folding unit With folding fingers.
Embossing unit

1- Steel to paper(wool), Male to female. (Steel to steel is available.)
2- Embossing pattern can be any LOGO, brand name, flowers etc.
3- Embossing pattern can be customized by client or recommended by us
4- Controlled by screws, mechanical pressing type. Cylinder type is optional.

Tension control

Speedless Tension control unit to fit the machine for paper of different quaity and different gsm.
With automatic web guiding system.
With automatic web tension control system.

Power 5.5Kw depends on requiremetns (3-phase AC380V 50Hz or customized)
Machine size 7x2x3m
Weight 4000KG
Videos and photos available.



D. Printing Section (advanced design.)

1. With 2 colors flexo-graphic printing units.

2. Printing unit with driven by timing belts to make printing more precise.

3. Simple and easy adjustment of horizontal and longitudinal registration by turning hand wheel.

4. With automatic printing roller disconnection device during machine stop. If the machine stops, the roller will automatically disconnect with the printing unit, controlled by pneumatic system.

5. The printing plate roller can be adjustable or disassembled from the printing unit, much easier for the operator to attach the printing rubber plates or clean the roller.

6. Both sides of Anilox roll & Rubber roll with buffer for anti-spill cover to stop the ink spilling out of the ink tank and spraying somewhere.

7. The printer is equipped with cover on the in tank to prevent the inks spilling out of the ink tanks.

8. With printing ink reservoir for reserve dropping ink and avoid ink dropping on machine or place to keep environment clean.


Function of this Taiwan Technology 2 Colors Printing N Fold Napkin Making Machine With 2 Channels 2500 Napkin/Minutes:
1. Embossing design on raw paper with clear embossing shape.
2.Count automatically and orderly placed, convenient to pack.
3. Controlled with rolling tension to fit production with different tension of raw paper.
4. Adopt double screw turning knife to cut fast and easy adjustment.
5. Adopt vacuum folding type.
6. As requested, this machine can be equipped with single color or double colors printing device.

Configuration of this Taiwan Technology 2 Colors Printing N Fold Napkin Making Machine With 2 Channels 2500 Napkin/Minutes:

Bearings NSK
PLC Siemens
Inverter Siemens
Touch screen Siemens
Auto web guide Italy Best
Auto tension system Like
Steel High Speed steel
Anilox Ceramix


D. Important parts:
1. Taiwan DELTA Inverter. Much easier for operation. (Other companies use only buttons and even all inferior buttons, easy to damage. And they use Elctromagnetic speed control, easy to get broken.)
2. Japan Omron sensors for detecting paper break. (Other companies use inferior brands)
3. Franch Schneider electrical parts like breakers, contactors and relays. (Other companies inferior brands made in China)
4. French Schneider buttons (Other companies use bad quality buttons)
5. The best China bearings, even Japan NSK bearings for the main aprts. (Other companies use cheap inferior brands bearings)
6. Taiwan Airtac cylinders. (Other companies use not that good brand)
7. The best brand motor made in China. (Other companies inferior brand)
8. Stronger structure and better quality parts than others. Complete thickened wallboard steel plate structure to ensure high speed running, no vibration.

FAQ for this Taiwan Technology 2 Colors Printing N Fold Napkin Making Machine With 2 Channels 2500 Napkin/Minutes.

Q: Are you trading company or manufacturer
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 60-90 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
