Product Details:
Payment & Shipping Terms:
|
| Machine Name: | Log Accumulator For JRT Roll | Log Accumulator Capacity: | 100 Logs Or 200 Logs |
|---|---|---|---|
| Working Material: | JRT Jumbo Roll Tissue | Log Width: | JRT Log 1300-4000mm |
| Log Loading Speed: | 20 Log/minute | Log Diameter: | 90-150mm Or 150-250mm |
| Highlight: | JRT Roll Log Accumulator,Jumbo Roll Log Accumulator,Log Accumulator Full Automatic |
||
Application of this
This ACE-LA100 Fully Automatic JRT Roll Log Accumulator for Jumbo Roll Tissue 200 logs is a first-in-first-out design used as a buffer of stored logs between the rewinder line and downstream equipment to help maintain consistent production during process upsets and changeovers. It is a log accumulator for toilet paper, kitchen towel, JRT, maxi roll, jumbo roll tissue and also nonwoven airlaid rolls automatically load the toilet paper log and unload the tissue paper log to the cutting machine like log saw cutting machine or automatic band saw. It can be used as a storage between the toilet paper kitchen towel rewinder machine and the log saw machine.
Quick details:
1 Mother roll width 1200mm – 4000mm
2 A log accumulator for toilet paper kitchen towel jumbo roll tissue and nonwoven airlaid rolls.
3 Fully automatic.
4 High speed
5 Can connect to rewinder machine and logsaw cutting machine
Technical parameters of this Fully Automatic JRT Roll Log Accumulator for Jumbo Roll Tissue 200 logs is as below
| Model | ACE-LA100 Log Accumulator | |||||||||
| Machine name | Fully Automatic JRT Roll Log Accumulator for Jumbo Roll Tissue 200 logs | |||||||||
| Mother roll width(mm) | 1300 | 1800 | 2000 | 2200 | 2400 | 2600 | 2800 | 3000 | 4000 | Customized |
| Log width | Up to 3000mm or customized | |||||||||
| Machine speed | about 20 log/minute. | |||||||||
| Raw material |
toilet paper |
|||||||||
| Log diameter | 90-140mm. or 150 - 250mm or customized. | |||||||||
| log accumulator storage capacity |
100 logs or customized 200 lgs or 60 logs etc. |
|||||||||
| Automatic |
fully automatic to work between the rewinder machine and the log saw cutting machine. |
|||||||||
| Point to point Lamination system |
a. With one complete sets of point to point lamination units. |
|||||||||
More specification of this High Speed Fully Automatic JRT Roll Log Accumulator for Jumbo Roll Tissue 200 logs.
1) The same safety devices as the other machines.
2) Automatic running, first log in, first log out, with automatic transfer into the log saw.
3) With 100 logs storage capacity, with two unloading system. (storage quantity can be confirmed.)
4) It will receive the logs from the rewinder, and discharge them into two saws, at the speed up to 20 logs/min.
5) Heavy frames, easy to assembly and disassembly to fit the container
FAQ of this High Speed Fully Automatic JRT Roll Log Accumulator for Jumbo Roll Tissue 200 logs:
Q7: why kitchen paper need to glue.(lamination)
A7: 1. After embossing, two plies of paper will be laminated by glue, and the paper will be even
fluffier than normal embossing.
2. Laminated paper could absorb more water more quickly, make the paper more useful
during cleanning.
3. Also, we could use color glue to make the paper more beatiful and attractive.
Welcome to contact us to find out more details of this Fully Automatic JRT Roll Log Accumulator for Jumbo Roll Tissue 200 logs.
