Automatic Kleenex Tissue Paper Interfolder Machine With Color Printing

Automatic Kleenex Tissue Paper Interfolder Machine With Color Printing
Automatic Kleenex Tissue Paper Interfolder Machine With Color Printing
video play

Large Image :  Automatic Kleenex Tissue Paper Interfolder Machine With Color Printing

Product Details:
Place of Origin: CHINA
Brand Name: ACE
Certification: CE
Model Number: ACE-V200-6L-L
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: standard export packing
Delivery Time: 60 days
Payment Terms: L/C, T/T
Supply Ability: 5 set /month
Detailed Product Description
Product: Kleenex Tissue Paper Interfolder Machine Other Name: Facial Tissue V Type Folding Machine With Printing
Priniting: 1 - 2 Colors Printing Cutoff Size: 190/ 200 / 230mm
Fold Type: Inter-folded / V Type Capacity: 1000 Sheet/min/line * 6lines
High Light:

6 Lanes Tissue Paper Interfolder Machine

,

Color Printing Tissue Paper Interfolder Machine

,

Automatic Interfolder tissue folding machine

Automatic Kleenex Tissue Paper Interfolder Machine With Color Printing​​​.


Application
This ACE-V200-6L-L
China Automatic Kleenex Tissue Paper Interfolder Machine With Color Printing is with both full embossing unit and edge embossing unit and point to point lamination unit. It is mainly used to automatically fold, emboss, cut and count facial tissue papers, soft drawing nylon pack facial tissue paper, box-drawing facial tissue papers, pop up tissue paper napkin, interleaved tissue paper, interfolded paper towel, V fold hand towels, nonwoven airlaid tissue, and MG paper napkins etc. all-in-one machine It adopts vacuum folding style. The mainly function of this machine is to manufacture commercial tissue paper products and away-from-home tissue paper products, easy-to-take one by one plain, embossed and LOGO printed and laminated interfolded dispenser napkins and V fold hand paper towels. It has 10 lanes output and can run at very high speed up to 1000 sheets per minute per lane. The jumbo roll width can be up to 2100mm. It has 4 unwinder jumbo roll stands which are driven by separate independent reduction motor, not chain and belt. It is an ideal equipment to manufacture high grade away-from-home customized embossed facial tissue paper napkin products.

Advantage:

1 Machine for interfold box facial tissue paper and v fold paper towel
2 With both full embossing and edge embossing.
3 high speed up to 1000 sheet/min/lane
5 Vacuum fold
6 With point to point gluing lamination unit.
7 Machine for Interleaved Paper Towel


Technical parameters as below

Model ACE-V200-6L-L
Output type 6lines High Speed Kleenex Tissue Paper Interfolder Machine
Folding speed 1000 piece/min/lane * 6lanes, depending on the paper quality and napkin size.
Raw paper

13-20g/m2 2-ply, 16-45g/m2 1-ply, wooden pulp paper or MG paper or nonwoven airlaid.
Other sizes please specify.

Jumbo roll size ≤ 2100mm x Φ1200mm (Depends on your napkin size, customized)
Napkin size

Open size: 200±2mm x 200/165/140mm Other size, please specify.
Folded size: 100±2mm x 200/165/140mm
Fixed cutoff size is 200m. Other size available, please specify. or Customized.

Folding type

Interfold / inter-folded
interleaved type
Vacuum fold
1/2 V fold.
single fold

Embossing unit

1- Steel to rubber. (Steel to steel is available.)
2- Embossing pattern can be any LOGO, brand name, flowers etc.
3- Embossing pattern can be customized by client or recommended by us
4- Controlled by screws, mechanical pressing type. Cylinder type is optional.
5- With edge embossing units.

Point to point Lamination system

Lamination system is optional.
a. With 2 complete sets of point to point lamination units.
b. The whole design is copied Italy design.
c. Heavy chrome coating roll
d. Micro-adjustment of nips between the steel roll
e. Anilox roll for glue applicant.
f. Controlled by cylinders
g. Each lamination unit controlled by an independent reducer. When the machine stops, the motor will start running to rotate the anilox roll to prevent it getting dry.

Tension control

Speedless Tension control unit to fit the machine for paper of different quaity and different gsm.
With automatic web guiding system.
With automatic web tension control system.

Power

7.5Kw for main motor
15KW for vacuum pump
(3-phase AC380V 50Hz or customized)

Machine size 6x2x2m
Weight 6T
Videos and photos available.


Free spare parts
1. Plastic tuckers. 4pcs
2. Band saws 4pcs
3. Timing belt 1 pc each type
4. tool kit



G. Printing Section (advanced design.) optional

1. With two colors printing flexo-graphic printer section.

2. Printing unit with driven by timing belts to make printing more precise.

3. Simple and easy adjustment of horizontal and longitudinal registration by turning hand wheel.

4. With automatic printing roller disconnection device during machine stop. If the machine stops, the roller will automatically disconnect with the printing unit, controlled by pneumatic system.

5. The printing plate roller can be adjustable or disassembled from the printing unit, much easier for the operator to attach the printing rubber plates or clean the roller.

6. Both sides of Anilox roll & Rubber roll with buffer for anti-spill cover to stop the ink spilling out of the ink tank and spraying somewhere.

7. The printer is equipped with cover on the in tank to prevent the inks spilling out of the ink tanks.



H. Control system

a. Speed: about 1000 piece/min/lane x 10 lanes. Depends on paper quality, workers etc.

b. Speed of production is controllable.

c. Main motor control by inverter

d. Automatic left-right stagger counting system, each stack of 100 pieces, 150pieces etc.

Configuration:

Bearings NSK
PLC Siemens or other brand
Inverter Siemens or INVT
Touch screen Siemens or DELTA
Auto web guide LIKE
Auto tension system Famous brand
Steel High Speed steel
Anilox Ceramix



Finished products by this China Automatic Facial Tissue V Type Folding Machine With Steel To Rubber Embossing:
 Tissue Paper Interfolder Machine with printing
