Name: | Napkin Making Machine With Printing | Speed: | 200m/min |
---|---|---|---|
Napkin Size: | 300x300mm Or Multi Sizes. | Folding Style: | 1/4 Type |
Color Register Tolerance: | ±0.1mm. | Printing: | Four Colors High Quality |
Highlight: | Single Lane Napkin Making Machine,200m/min Napkin Making Machine,1/4 Folding Napkin Printing Equipment |
Application
This ACE-TNM-4C Napkin Making Machine With High Quality Four Colors Printing is mainly used for production of high quality four color printing on napkins. It is with high resolution and color register tolerance ± 0.1mm. It can automatically fold, emboss, print, cut and count 1/4 fold table napkins, cocktail napkin, restaurant napkins, beverage napkin, lunchen napkin, 1/6 fold tallfold dispenser napkin, wallet tissue and MG paper napkins etc. The mainly function of this machine is to make multi colors printed high resolution high quality printing of four colors printing up to eight colors. This napkin making machine with four colors printing can be also print up to 8 colors or point to point lamination.
Advantage:
1 Best napkin making machine with four colors.
2 High resolution printing machine.
3 With four colors printing.
4 With auto web tension system
5 With auto edge guiding system
6- Color register tolerance: ±0.1mm.
7- napkin making machine manufacturer since 1992.
Technical parameters as below
Italy Design Automatic High Speed Four Colors Printing Paper Napkin Machine
Model | ACE-TNM-4C the best quality napkin making machine with four colors printing |
Output type | single lane |
Folding speed |
200 m/min, about 400-700 piece/min, depending on the paper quality and napkin size. |
Raw paper |
13-20g/m2 2-ply, 20-45g/m2 1-ply, wooden pulp paper or others. Other sizes please specify. |
Jumbo roll size | ≤ (200-460)mm x Φ1200mm (Depending on your napkin size,customized) |
Napkin unfolded size | 200mm x 200mm to 460mm x 460mm or Customized. |
Napkin folded size |
100mm x 100mm to 230mm x 230mm One size is fixed. One napkin size is adjustable, decided by the paper roll width. |
Folding type |
Mechanical fold with band saw cutting; 1/4 fold; Vacuum folding and other folding types available. |
Printing unit |
1- Flexo printing type. 2- Printing colors customized up to four colors printing. Color register tolerance: ± 0.1mm. 3- Printing Logo is changeable. You just need to change the Printing Rubber only. 4- With ceramix Anilox roll to transfer the inks. 5- Printing roll is adjustable. 6- Ink printing system to be negotiated. |
Tension control |
Speedless Tension control unit to fit the machine for paper of different quaity and different gsm. With automatic web guiding system. With automatic web tension control system. |
Power | 10Kw depends on requiremetns (3-phase AC380V 50Hz or customized) |
Machine size | 7x2x3m |
Weight | 4000KG |
Videos and photos available. |
B. Feeding Section
1. With 1 unwind stands;
2. Floor-standing thickened Wallboard structure (complete steel plate) to ensure high speed stable running no vibration.
3. Pneumatic cylinder control
4. Stepless adjusting speed to control web-tension of paper.
5. Auto adjustment setting
6. With pneumatic system to automatically load jumbo rolls.
7. With automatic web tension control system. Web tension control: constant tension control by floating roll.
8. With automatic edge guiding system. Automatic electrical deviation control: Internationally famous brand.
9. Paper transport: step-less speed regulating (triangular belt).
B. Feeding Section
1. With 1 unwind stands;
2. Floor-standing thickened Wallboard structure (complete steel plate) to ensure high speed stable running no vibration.
3. Pneumatic cylinder control
4. Stepless adjusting speed to control web-tension of paper.
5. Auto adjustment setting
6. With pneumatic system to automatically load jumbo rolls.
7. With automatic web tension control system. Web tension control: constant tension control by floating roll.
8. With automatic edge guiding system. Automatic electrical deviation control: Internationally famous brand.
9. Paper transport: step-less speed regulating (triangular belt).
C. Embossing Section
1. One set of steel to paper embossing unit. (Embossing pattern provided by client or recommend by us)
2. Mechanical press type.
3. Floor-standing thickened Wallboard structure(complete steel plate) to ensure high speed stable running no vibration.
4. With 1 set of steel to steel Calendering unit.
F. Control system
1. With JOG function.
2. With emergency stop function.
3. With auto sensors for detecting paper breaks or used up. Machine will automatically stop if paper breaks or used up.
4. Famous brand motor and bearings.
5. Installed Power: total about 11.7 kw (3-phase AC380V 50Hz or customized)
-Main motor power: 4.5kw
-Band saw: 2.2KW
-Heating dryer: 2KW
-Lighting: 1KW
-Others: 2KW
6. Pressure: 0.5MPa.
7. Machine size about ( L*W*H) 6050*1530*2500mm
8. Weight: about 4000 kg
Configuration:
Bearings | NSK |
PLC | Siemens |
Inverter | Siemens |
Touch screen | Siemens |
Auto web guide | Italy Best |
Auto tension system | Like |
Steel | High Speed steel |
Anilox | Ceramix |
Products made by this Napkin Making Machine With High Quality Four Colors Printing for reference.:
